Skid Steer Attachments / Grapples
We at MTL try to update the site daily with grapples that are both starting production & being finished and try to get these shipped out very quickly to fulfill orders. You can place Pre orders direct or any special orders by calling (404)-433-5364 Mon-Fri 9-4 EST.
MTL X Series Rock Grapple Bucket w/teeth - multiple sizes available
MTL X Series Rock Grapple Bucket w/teeth - multiple sizes available
Brand new Built in the USA MTL X Series Rock Bucket Grapple with teeth 66” / 72", 80" & 84" / universal fit.
ALL MTL X series is the top of the line series and uses all premier parts for construction - giving added value to an already comparably priced product that is normally around 1/2 that of all our Major competitors.
Clear rocks quickly and easily with our MTL X-Series 80" Rock Grapple! Constructed from high-tensile strength, 3/8" , 1/2" & 4" box Square Tubing steel, our X-Series Rock Grapples Are Made to last through the harshest conditions, and most severe use out there.
The big 20T Pengo style pin on replaceable teeth can easily rip into the earth, lifting rocks and other debris from the soil. Dirt and smaller objects easily fall through the slotted true 3" spacing bottom.
• X-Series Rock Grapple Bucket"
• 20T Pengo 230 style REPLACEABLE pin on Teeth w/ weld on solid shank
• Grease fittings on every moveable part.
• 3000 psi clamp force
• Houses routed through tubing to prevent damage during use
• 100% powder coated for long durability.
• High Grade AR400 3/4" thick x 6" wide High Carbon hardened cutting edge
• True 3" spacing using solid A36 3/8" steel. (center to center is 2.9")
• Extra Heavy Duty Tongs w/ solid plates to prevent cylinder damage.
• Cylinder and Now new ROD - Covers to completely prevent falling damage
• Cylinders are serviceable , can be rebuilt, repacked at any hydraulics company.
Complete with all flat faced couplers and ready to use - no extra parts are needed.
• Extra Deep design gives great visibility
• Extra HD design built for up to 110 hp machines
• Available in 66”, 72", 80" & 84"
• This is comparable to Top of the line Bradco or Blue Diamond models that cost $4000 +
Weights are as follows:
66” - 1012 lbs
72” - 1064 lbs
80” - 1110 lbs
84” - 1158 lbs
OUR MTL X series line is buy it once and you're done line. The X-line is MADE TO LAST.
The complete MTL line is built in the USA, by hard working families living in the USA
Universal skid steer fitment - Fits 99% of all skid steers manufactured after 1990.
We have used them on Bobcat, Cat's, ASV and John Deere's with no problem.
